    New Yard LLC Marine Storage Building

    placeholder-1140x400

    The Rundown

    This clearspan fabric building in Portland, Maine, is insulated and climate controlled to create a dry interior for boat storage. The skylight allows natural light into the building for a more pleasant, natural-feeling environment.

    Feature Details

    • Building size: 120 ft x 160 ft with an 18-ft interior eave height and 3-ft overhangs
    • Designed with specific clearances to meet zoning maximums and interior required volume
    • Includes load design for sprinkler system, interior circulation fans and future expansion
    • End wall engineered for two 20 ft x 20 ft high-lift overhead doors and one 30 ft x 30 ft bi-fold loading door
    • Exclusive interior liner system with active cavity ventilation system for energy efficiencies
    • Active gable peak-mounted intake and exhaust system
    • Exterior light and camera mounts plus bird deterrent system
    • Legacy-designed ice breakers on roof edges
    • Structure has bi-level foundation and interior base slope of 2/12
    • 60 psf ground snow load, 110 mph windspeed, seismic C
    • Building was delivered and installed on time and on budget
    • Building use: Marine storage building

    Industry

    Ports & Waterways

    Size

    19,200 sq ft

    Location

    Portland, ME

    Year

    2013
